20C GLADIATOR JT: 70IN CRD60 HD REAR AXLE W/ FULLFLOAT NO R&P LOCKER CARRI

Extreme duty full-float design axle assembly for JL Wrangler/Unlimited and JT Gladiator. Features full-float outer axles, Super 60 bearings, inner axle shafts, and sensors. Constant Radius Design (CRD) for high ground clearance. Compatible with all Super 60 gear ratios. Includes 3.25" O.D. x 0.375" wall DOM axle tube, 70" WMS-WMS, 8x6.5" wheel bolt pattern, fixed spindle mount hub, Tera CRD60 specific high-pinion housing, 1350 series pinion yoke, 35-spline inner and outer stub shafts, HD bearing caps, built-in "skimmer," renewable outer pinion bearing oil reservoir, oversized outer pinion bearing, high-capacity housing, pre-installed inner axle seals, ductile cast iron housing, HD ductile iron differential cover, integrated lower control arm skid plates, high-flow oil passages, bottom oil drain hole, reinforced rear track bar mount, UV protected triple-stage powder coat, 1/4"-thick CNC laser cut axle brackets, pre-installed upper control arm bushings, proper pinion angle and raised track bar bracket for lifted applications, pre-tapped hole for bump stop extensions, pre-drilled holes for limit straps and lower spring retainers. Retains all JT ESP, ABS, and speedometer sensor capability. 100% engineered, designed, and built in the USA. 1-Year/Unlimited Mileage Warranty.
