347 Crate Engine 415 HP

The BluePrint Engines Universal AM Small Block Ford 347 C.I. 415 HP Deluxe Dressed Fuel Injected Crate Engine (BP3479CTFD) is built for performance applications. This engine boasts a new, high-strength cast iron block with enhanced durability features like increased deck thickness and strength webbing, priority main oiling, a 4-bolt main, and a 1-piece rear main seal. The rotating assembly is comprised of a 3.400" stroke, forged 5.400" connecting rods, and forged pistons, all balanced externally to 28oz. Equipped with BluePrint aluminum cylinder heads (HP9009) featuring 60cc chambers, 2.02" intake valves, and 1.60" exhaust valves, this engine offers efficient airflow with 190cc intake and 60cc exhaust runners. The camshaft is a hydraulic roller with .543 intake / .554 exhaust lift and 218 intake / 226 exhaust duration at .050 lift, on a 112-degree lobe separation. The ignition timing is recommended at 10-16 degrees initial and 32-34 degrees total. This deluxe dressed crate engine comes complete with a front sump oil pan, intake manifold, EFI system, distributor, spark plugs and wires, water pump, harmonic balancer, valve covers, timing cover, and thermostat with housing.
