5000 Series T3 Two-Piece Performance Brake Rotor

The DBA 5000 Series T3 brake rotor is a high-performance, two-piece direct replacement rotor from Disc Brakes Australia (DBA). Designed for drivers seeking to enhance their vehicle's braking capabilities beyond standard OE levels, this rotor features DBA’s patented T3 bi-directional slot design. The T3 slots are CNC-machined with tri-symmetrical patterns to promote quieter, more responsive, and smoother braking by increasing the exit points for brake pad friction dust and gases. Constructed from high carbon alloyed iron, the 5000 Series T3 rotors undergo Thermal Stability Profiling (TSP). This process allows the rotor's metallurgy to withstand higher stress and heat generated during intense braking applications. This enhanced cooling is crucial for maintaining consistent braking performance under demanding conditions. This particular rotor, part number DBA52466BLKS, is designed for the front axle and features a slotted surface type. Key technical specifications include an outside diameter of 340mm, an overall height of 56.5mm, a nominal and discard thickness of 28.5mm, a center hole diameter of 69mm, 5 lug holes, and a pitch circle diameter of 114.3mm. The rotor utilizes R KP Vents for its vane design.
