5000 Series XS 2-Piece Front Brake Rotor

The DBA 5000 Series XS is a fully assembled 2-piece front brake rotor engineered by Disc Brakes Australia (DBA) for drivers seeking performance braking enhancements beyond standard OE levels. This rotor is constructed from high-carbon alloyed iron that has undergone Thermal Stability Profiling (TSP), allowing the metallurgy to withstand the increased stress and heat generated during intense braking applications. The 5000 Series XS rotor features DBA's patented Kangaroo Paw ventilation system, which utilizes a series of diamond and teardrop-patterned pillars. Additionally, the premium non-directional XS rotor incorporates a cross-drilled and slotted surface design. This unique pattern increases the number of exit points for brake pad friction dust and gases, contributing to better braking performance. While offering similar performance benefits to the T3 slot, the XS design is also noted as a popular alternative for show cars. Key technical specifications for the DBA52224BLKXS include an outside diameter of 350mm, a vented rotor type, and a 5-lug hole configuration. The rotor has a nominal thickness of 32mm, a minimum thickness of 30mm, and an overall height of 43.5mm. The center hole diameter is 69mm, and the pitch circle diameter is 114.3mm.
