5000 Series XS 322.5mm Front Brake Rotor

The DBA 5000 Series XS Brake Rotor is engineered for drivers seeking enhanced braking performance that surpasses standard OE levels. This rotor features a premium, non-directional cross-drilled and slotted design, which is a popular choice for show cars while delivering significant performance benefits. The unique XS design increases the number of exit points for brake pad friction dust and gases. By allowing these elements to escape through both the cross-drilled holes and slots, the rotor helps maintain optimal braking performance, especially under demanding conditions. This design contributes to better stopping power and heat dissipation. This front rotor has a 322.5mm outer diameter, 45mm height, and a 24mm disc thickness, with a minimum thickness of 22mm. It utilizes KP Vents for effective cooling and features a 148mm centering diameter and a 114.30mm pitch circle diameter with 5 holes. The rotor is constructed from high carbon alloyed iron and has undergone Thermal Stability Profiling (TSP) to handle increased stress and heat generated during intense braking applications.
