6061-T6 Aluminum Oil Cooler Adapter with Thermostat

The Improved Racing low-profile oil cooler adapter (EGM-112-T6) directly replaces the factory GM LS oil bypass cover, situated just above the oil filter, to integrate an oil cooler setup. This adapter is engineered with an integrated thermostat that activates at 200°F (93.3°C), helping to reduce engine wear and horsepower loss by preventing oil temperatures from dropping below optimal levels. It maintains a minimum oil temperature of 200°F (93°C) +/- 5°F under most conditions, facilitating quicker engine warm-up, especially in colder weather. The unit's low-profile design, with a maximum thickness of 1.30 inches, is specifically crafted to provide maximum header clearance, fitting most long tube headers, including those found in FD RX-7 LS swaps with JTR and Spoolin Performance headers. Constructed from a single piece of 6061-T6 billet aluminum with a black MIL-A-8625 Type II anodized finish, the adapter features Viton seals throughout and comes with a Lifetime Warranty, proudly made in the USA. It utilizes standard female -8AN O-ring boss ports, requiring specific Improved Racing fittings for guaranteed proper thermostat operation and fitment. An optional 1/8" NPT oil temperature sensor is available to retain the factory oil temperature gauge functionality on 1997-2004 Chevrolet Corvette (C5) models. This adapter is compatible with all 1997 and later GM LS family engines (Gen III & IV) with rear-sump oil pans, including LS1/LS6, LS2, LS3, LS7, L76/L92/L93, LQ4/LQ9, LS9, and LSA, as well as all GM Gen III & IV Vortec V8 engines. It does not fit iron block LSX engines without notching and is NOT suitable for front-sump pans found on vehicles like the Pontiac GTO or Holden/Vauxhall Monaro & Commodore. Installation notes detail specific AN fitting recommendations for Corvette and F-Body motor mounts and potential adjustments for knock sensors on Gen IV LS engines.
