80LB Short EV1 Fuel Injector

The Siemens Deka 80LB Short EV1 fuel injector is a high-impedance injector designed for performance applications, offering a flow rate of 80 lbs/hr at 43.5 PSI (3 BAR). These injectors are known for their linear and controllable performance at low pulse widths, even with their high flow rate, which has led to their use in ULEV (Ultra-Low Emission Vehicle) applications. This capability allows for the use of larger injectors without negatively impacting idle and low-speed driveability. These injectors are built with a robust design and provide excellent response characteristics. Their high-impedance nature makes them compatible with most ECUs and factory ECM/PCM injector drivers, while still delivering substantial flow. This design avoids the common issues found in other high-flow, high-impedance injectors when subjected to high pressures. Based on the popular FI114992 model, these injectors feature the Minitimer EV1 connector, commonly found on many OEM applications including GM TBI, TPI, LT1, LT4, LS1, some LS2, some LS6, and most European vehicles. This direct compatibility eliminates the need for adapters or modifications to factory connectors. Key specifications include a static flow rate of 80lb/hr (875 cc/min), a coil resistance of 12 Ohms, and Viton O-rings. The series is DEKA 4 (DEKA IV).
