9-Inch 10-Row Round Oil Cooler Kit

The Earls 14032210 is a high-performance round oil cooler kit engineered to enhance the cooling efficiency of select Honda motorcycles. This kit emphasizes lightweight design, compact size, and superior performance, utilizing trusted Earls components for both the core and fittings. This specific kit is designed with a 9-inch, 10-row core and utilizes #6 size hoses, arranged in a standard routing configuration. The included hose set features specific fitting data: the long hose is a 90° to straight configuration, while the short hose is a 45° to straight configuration. The kit comes complete with vehicle-specific mounting brackets made by Active. Installation notes indicate that the oil lines must be routed carefully to avoid contact with the engine or exhaust system. The kit is set up based on the normal muffler configuration. It's important to note that the oil take-off is integrated into the oil filter base, which will cause the oil filter to be positioned approximately 30mm further forward after installation. This Earls oil cooler kit is specifically designed for the HONDA CB400SB from model years 2005 to 2006 and the HONDA CB400SF VTEC 2/3 from model years 2002 to 2006.
