ALL-IN-ONE 240V 50 AMP AC/DC PANEL

Replacement fuse board with Lithium switch. 4-30 amp, 14-20 amp Maximum fuse positions. Not compatible with converter sections that did not previously have the switch. Part number 814523. The AC Distribution Panel is rated for 240 VAC @ 50 AMPS. Provisions for up to 12 branch breakers (breakers not included). Center feed dual 50 AMP main breaker (not included). AC Panel features 12 built-in push and lock strain relief wiring connectors for quick installation. Saves over 50% on installation cost. Vertical or horizontal mounting choices. Attractive light weight panel design made from impact-resistant high temperature polymers. Top two fuse holders recommended for low current devices such as smoke detectors and carbon monoxide detectors. 18 Branch fuse holders with maximum rating of 20 AMP. Optional L.E.D. indicators identify which fuse is blown. Converter/Charger section is accessible from the front. Converter/Charger ratings of 60, 75 and 90 AMP, which is the largest rating available in the industry. Easy access reverse battery protection fuses. Optional DC Ground Buss can be user-installed in the DC wiring compartment.
