Artec Industries 78-90 Ram 3500 Easy 3 Link - Kit I - Dual Bracket - Outside Frame Dodge - No Dom

Part #: LK0306

Our Easy 3-Link Kit I is the simplest way to get your links done. This kit is based off our most popular parts we've sold our customers for a 3-link with panhard bar. This kit is intended for axles without a front truss. If you have one of our 60 front trusses, choose Kit F. The heat and cryogenically treated chromoly rod ends are the strongest and longest lasting on the market.The included tube adapters feature machined Wrench Flats for easy adjustments and tightening and conform to the outer diameter of the tubing it welds to. The included stainless steel high misalignment spacers allow for maximum articulation in the rod end. As an option, this kit offers four foot lengths of both 1.5 inch and 2.0 inch tubing to be cut to the exact length needed for your particular vehicle.Includes:1 RH, 1 LH - 7/8 inch -14tpi x 3/4 inch bore rod ends for panhard1 RH, 1 LH - 7/8 inch -14tpi Tube Adapters for panhard1 RH, 1 LH - 7/8 inch -14tpi Jam nuts for panhard4 - 3/4 inch-9/16 inch High Misalignment Spacers3 RH, 3 LH - 1.25 inch -12tpi x 1.0 inch bore rod ends3 RH, 3 LH - 1.25 inch -12tpi Tube Adapters3 RH, 3 LH - 1.25 inch -12tpi Jam nuts12 - 1.0 inch-3/4 inch High Misalignment Spacers1 - Pair Lower Link Axle Brackets (10 deg)1 - Single Truss Upper Link Mount (2.63 inch)1 - Dual 3 Link Bracket1 - Adjustable Panhard Frame Mount1 - Adjustable Panhard Truss Mount1 - 4 ft 1.5 inch OD .250 inch thick DOM tubing (optional)3 - 4 ft 2.0 inch OD .250 inch thick DOM tubing (optional)Note: This kit will require drilling of lower link holes to 3/4 inch unless you specify you'd like 9/16 inch bolts for your lower links.Features:Easy 3 LinkKit IDual Bracket for Artec TrussOutside FrameDodgeNo Dom TubingSold As: Kit
