DRIVE SHAFT

The Dana 804848-0300 is a Spicer Diamond Series 1810 commercial-grade driveshaft assembly. It features a 4.50-inch diameter tube with a 0.134-inch wall thickness. This assembly is designed for heavy-duty applications requiring precise slip and joint angle tolerances.

Engineered with a 33.5-degree joint angle and 5 inches of maximum slip capacity, this driveshaft assembly ensures robust power transmission in commercial vehicle configurations. It measures 20 inches from centerline-to-centerline of the yokes when collapsed, and 22.5 inches to the end of the spline sleeve.

This component is universal-fit based on its engineering specifications rather than specific vehicle model years. Installers should match the driveshaft series, tube diameter, length, and yoke dimensions to the existing powertrain setup for proper application.

The Spicer Diamond Series is recognized for its durability and performance under heavy load conditions. These units are built to meet rigorous standards for commercial and industrial use in the United States.
