DRIVESHAFT

The Dana 805983-2823 is an 1810 Series driveshaft assembly designed for heavy-duty commercial vehicle applications. As a precision-engineered Spicer component, it features a 4.50-inch diameter tube with a 0.259-inch wall thickness, built to withstand the rigorous torque demands of heavy industrial equipment.

This driveshaft assembly features a collapsed end-to-end length of 45.9707 inches and a tube length of 28.7188 inches, providing a 5.00-inch maximum slip. Constructed from heavy-duty steel, it is a direct replacement for various commercial truck and specialty vehicle applications.

Installation of this driveshaft should be performed by experienced technicians, ensuring proper phasing and universal joint angles to prevent drivetrain vibration and premature wear. Ensure all mounting surfaces are clean and hardware is torqued to manufacturer specifications.

Compatibility is determined by technical dimensions and driveshaft series rather than specific vehicle make and model. Always measure your existing driveshaft and verify the 1810 series flange bolt pattern prior to installation. It is commonly cross-referenced with parts from Emergency One, Navistar, and Volvo.
