Edelbrock 15-17 Ford Coyote Pro-Flo 4+ EFI Engine Management System

Edelbrock Pro-Flo 4 Plus systems simplify EFI for late model Ford Coyote, Chevrolet LS, and Mopar Gen III Hemi engines in hot rod transplant applications. Each package consists of an ECU, wiring harness, and a 7 in. wireless touch screen tablet for programming, calibration adjustments, and monitoring performance. All systems are plug-and-play and are supported by a standalone Edelbrock Android app "E Tuner 4 Plus." No laptop tuning required, base calibrations are provided, and systems are self-learning for great out-of-the-box performance. Features include full VCT control, control for up to two drive-by-wire throttle bodies (LS applications), dual on-board wideband oxygen sensors with left and right bank closed loop AFR control using Bosch LSU4.9 sensors, knock control using OEM sensors (harness sold separately), high impedance injector drivers, and a simplified tuning interface for wireless Bluetooth tuning with an Android device. The system boasts refined base calibrations, a cosmetically appealing, fully terminated, modular wiring harness for easy installation, and a fully potted and weatherproof compact ECU design. It supports VCT phasers without additional modules, utilizes stock or 87mm GT350 drive-by-wire throttle body, works with most intake manifolds, and improves throttle response. Also supports knock control with additional harness. Requires the use of a DBW throttle body.
