FAG Deep Groove Ball Bearing

The FAG 515828 is a deep groove ball bearing designed for various applications, identified by its single-row configuration. This bearing is constructed with a steel or standard cage and a cylindrical bore. Key specifications include an inner diameter of 25 mm (0.9843 inches) and an outer diameter of 67 mm (2.6378 inches), with a width of 19 mm (0.748 inches). It operates with normal internal play and standard precision, and is lubricated to standard specifications. The bearing can withstand temperatures up to 120 °C without heat stabilization and has no external modifications or special treatments. This FAG bearing (part number 515828) is also known by the alternative number 361101A. It is specifically referenced as a Manual Trans Main Shaft Bearing, with applications noted for certain VW transmissions, including 1961-1972 VW Type 1 and 1961-1967 VW Type 2 models, and rear driveshafts in some VW applications. While the product is listed with a Toyota brand context, evidence points to its primary application in specific VW transmissions.
