FUEL FLOW SENSOR PACK

The Lowrance 000-11517-001 Electronic Fuel Flow Sensor with NMEA2000 and T-Connector provides real-time fuel consumption data for gasoline-powered outboards. It tracks engine fuel flow, fuel used, trip fuel used, and seasonal fuel used, displaying this information on any compatible NMEA 2000 network display. When connected to a speed source, it also calculates fuel economy. Designed for 3/8-inch (9.5mm) inside diameter gasoline-only fuel lines, it measures flow rates from 0.6 to 45 gallons per hour with minimal back pressure. The sensor includes a 10-foot cable, an N2K T-connector, and two 1-inch hose clamps for easy integration. One sensor is required per engine, with support for up to three engines on the network. Installation is recommended above the fuel tank's maximum fill level, in-line after the fuel filter and any Y-splitters.
