GM 4WD 4L80E SPD

Engine Specifications: • HP: 480 • TQ: 500 • Block: Seasoned OE roller block 1993-1997 • Bore/Stroke: 4.040 x 4.000 • Displacement: 408 • Crankshaft: Scat 4340 forged internal balance • Rods: Scat 4340 forged H beam with ARP 8740 bolts • Pistons: Forged 10.1 compression • Rings: Moly • Camshaft: Hyd. Roller • Cam Specs: 235/238 @50 .573in/.582ex 112LSA • Timing Chain: Double roller • Cylinder Heads: ATK HP aluminum 58cc/205cc 2.02/1.60 • Rocker Arms: Billet aluminum roller rockers 1.6 ratio • Oil Pan: Moroso front sump 7qt street/strip pan • Oil Pump: Melling high volume Recommended Components: • Balancer: Internal balance • Flexplate/Flywheel: Internal balance • Intake Manifold: Edelbrock performer RPM air gap dual plane • Distributor: Pro billet (with upgraded melonite or steel gear) • Water Pump: Early RH inlet standard rotation • Carburetor: Quick Fuel 770CFM vacuum secondaries electric choke #BR-67258 • Fuel Pump: Mechanical 110GPH • Spark Plugs: Autolite #3923 • Spark Plug Wires: 8mm Engine Info: • Oil: Conventional / Non Synthetic 10W30 • Oil Filter: Wix or K&N per application • Timing: 34-36 Degrees • Spark Plug Gap: .035” • Firing Order: 13726548 • Octane: 91+ • Stall Converter: 2500+ • Exhaust: 1 3/4 Headers Disclaimer: The parts listed are ATK’s recommendations of parts to be used to obtain our power figures listed. Power figures can vary based on parts used by the end user. It is the customer’s responsibility to verify components will work in their application. Some modifications to the vehicle may be required using these and other aftermarket parts. ATK reserves the right to substitute parts used in engines if necessary.
