HM Series 6-Way Unsealed Connector

The Sumitomo 6090-1218 is a 6-position, unsealed female connector from the HM series, designed for automotive inline applications. This connector utilizes brass for its contact material, ensuring reliable conductivity, and is housed in durable 66 nylon with a natural color finish. It is specified for 2.3mm (090) terminals and features a two-row configuration. Key electrical specifications include a maximum initial contact resistance of 3mΩ, which increases to a maximum of 10mΩ after durability tests. The connector also exhibits a maximum leak current of 3mA and a minimum insulation resistance of 100MΩ. It is noted that this is an "old series" connector, with mating parts such as 6090-1149 and 6090-1124 also from the HM series. The Sumitomo 6090-1218 connector is compatible with a wide range of vehicle applications, including but not limited to BMW 335i F30, Dodge Ram 5.9L Cummins ISB, Duramax 6.6L LB7 2003, Ford Mustang 5.0L V8, various GM LS and LT series engines, Honda Fit and K-series engines, Mazda Miata models, Nissan VQ35 and VR38DETT engines, Subaru BRZ, and Toyota 1JZ, 1UZ-FE, 2JZ families, and MR2 Turbo.
