2021-2023 Ford Bronco Hoss 2.0 Pkg Front 0-2 Inch Lift 2.5 Exp Series Coilover Icon Vehicle Dynamics

Part #: 48602

The 2021-2023 Ford Bronco EXP Series front shock absorbers by ICON Vehicle Dynamics combine the performance of a fully rebuildable 2.5-inch diameter premium shock absorber with the convenience and cost-benefits of re-using the Bronco's factory coil spring and other components. EXP bridges the gap between spacer lifts and threaded bodied coilovers, providing suspension lift, custom-tuned performance and maximum travel, all in an economical package.Features and Benefits:EXP Series is based on ICON's proven 2.5-inch diameter Aluminum Series shock absorber, featuring a one-piece impact-extruded aluminum shock body. Hard anodizing provides a great-looking, consistent finish with superior resistance to abrasion and corrosion. The massive 7/8-inch diameter shaft is induction hardened and chrome plated. EXP shocks use the factory shaft-up orientation, with the shaft ends machined to re-use the Bronco's OE upper shock and spring mounts.The 6061-billet aluminum coil spring seat is CNC machined to fit the molded heavy duty urethane coil spring seat that is specifically design for fit each of the Bronco model's OE coil springs. A series of snap-ring grooves machined into the shock body provide easily-selectable front-end ride height adjustment from 0 Inch to 2 Inch of lift over stock on Bronco's equipped with the OE HOSS 2.0 suspension package.EXP Series shocks utilize a one-piece digressive piston design and are custom tuned for the Bronco in conjunction with their stock coil springs to maximize damping performance and provide unsurpassed ride quality, on and off-road. The increased piston size and shock oil volume provided by the 2.5-inch diameter aluminum body also provide superior heat dissipation compared to the smaller, steel bodied OE shocks, resulting in longer-lasting shock performance over prolonged use at higher speeds and through rougher terrain. For those who would like to further tune their suspension, EXP shocks are fully re-valvable (and rebuildable) by any qualified shock technician, with parts available from ICON.HOSS 2.0 is Ford's upgraded suspension system for Broncos of the Base, Big Bend, Outer Banks and Black Diamond trim levels WITH the optional Sasquatch package, and it is also standard on Badlands, Wildtrak, First Edition and Everglades. HOSS 2.0 is most easily identified by the YELLOW shock bodies of the OE shocks.Vehicle specific design for 2021-2023 Ford Bronco with HOSS. 2.0 Suspension PackageVehicle specific tuned for superior shock damping and control2.5 Aluminum Series Shock with Internal ReservoirAdjustable ride heights from 0-2 Inch of front lift over stock with the use of snap ringUtilizes factory coil and coil hardwareInverted shaft up design featuring 7/8 Inch diameter, induction hardened, chrome plated shaftOne-piece, impact extruded, hard anodized aluminum cylinder offer excellent corrosion resistance and consistent finishCNC machined 6061 aluminum components with a black anodized finishPTFE lined spherical bearing for extended longevity and minimal deflectionHigh strength alloy CNC machined lower bar pin100 Percent Bolt-on - no cutting or welding necessary for installationFully rebuildable and re-tunableDetailsMaterial: Steel, AluminumActive Or Passive Suspension: PassiveAdjustable Compression: NoAdjustable Damping: NoAdjustable Height: YesAdjustable Rebound: NoBody Diameter: 2.5 InchBoot Included: NoCoil Over Springs Included: NoCylinder Color: GrayCylinder Finish: Hard AnodizedCylinder Material: AluminumDamping Type: OilDust Shield: NoDust Shield Included: NoGas Charged: YesGrade Type: PerformanceInternal Construction Type: Single TubeLower Mount Type: Bar PinMaximum Lift: 2.0 InchMinimum Lift: 0.0 InchOem Wheels & Tires Fitment: YesRecommended Aftermarket Tires: (Without Sasquatch Package): 35 Inch X 12.50 Inch (Requires High Clearance Crash Bars, Icon Part Number 42000. 37 Inch Tire Packages Require Trimming And Modifications), (With Sasquatch Package): 35 Inch X 12.50 Inch (37 Inch Tire Packages May Require Fender Trimming And Modifications)Recommended Aftermarket Wheels: (Without Sasquatch Package): Icon Alloys - 17x8.5 Inch W/ 5.75 Inch Backspace / 25mm Offset, (With Sasquatch Package): Icon Alloys - 20x9 Inch W/ 5 Inch Backspace / 0mm Offset, (With Sasquatch Package): Icon Alloys - 17x8.5 Inch W/ 4.75 Inch Backspace / 0mm Offset, (With Sasquatch Package): Icon Alloys - 18x9 Inch W/ 5 Inch Backspace / 0mm OffsetRemote Reservoir: NoReservoir Style: InternalSelf Leveling: NoService Parts: 252010 - 2.5 Ifp Rebuild KitShaft Diameter: 0.875Shock Absorber Body End Measuring Point: Top Of Upper Mount PlateShock Absorber Rod End Measuring Point: Flat On Bar PinSpring Color: BlackSpring Rate Type: LinearUpper Mount Type: Mounting PlateValving Type: DigressiveAdd On Part: 611082 - Exp 1 Inch Shaft Bump Extension, 48500DJ - 21-23 Bronco Billet UCA Dj Pro Kit, 42000 - 21-23 Bronco High Clearance Crash Bar Kit, 45212 - 21-23 Bronco XD Tie Rod Kit, 48400DJ - 21-23 Bronco Tubular UCA Dj Pro Kit

Features:

• Vehicle specific design for 2021-2023 Ford Bronco with HOSS. 2.0 Suspension Package
• Vehicle specific tuned for superior shock damping and control
• 2.5 Aluminum Series Shock with Internal Reservoir
• Adjustable ride heights from 0-2" of front lift over stock with the use of snap ring
• Utilizes factory coil and coil hardware
• Inverted shaft up design featuring 7/8" diameter, induction hardened, chrome plated shaft
• One-piece, impact extruded, hard anodized aluminum cylinder offer excellent corrosion resistance and consistent finish
• CNC machined 6061 aluminum components with a black anodized finish
• PTFE lined spherical bearing for extended longevity and minimal deflection
• High strength alloy CNC machined lower bar pin
• 100% Bolt-on - no cutting or welding necessary for installation
• Fully rebuildable and re-tunable

Based on ICON's 2.5 Series, these EXP shocks bridge the gap between spacer lifts and threaded bodied coilovers, providing suspension lift, custom-tuned performance, and maximum travel, all in one economical package.
