2024-2025 Toyota Tacoma 1.25-3 Inch Lift Stage 2 Suspension System Billet Triple Rate Rear Springs Icon Vehicle Dynamics

ICON Vehicle Dynamics 2024-2025 Toyota Tacoma suspension systems are designed for maximum performance, increasing wheel travel and damping for outstanding vehicle control and ride quality both on- and off-road. This Stage 2 system includes vehicle-specific tuned 2.5 Series coilover shocks with internal reservoirs and ICON-engineered coil springs. Coilovers are height adjustable from 1.25-3” of front lift, allowing for larger wheel and tire combinations. Front differential drop brackets and specific coilover lengths maximize front suspension travel and prevent CV bind. Polyurethane differential mounting bushings limit differential movement. The ICON billet aluminum upper control arm kit improves front-end geometry, increases on-vehicle camber and caster adjustment, and enhances suspension component clearance. The serviceable and rebuildable ICON Delta Joint PRO replaces the OE ball joint, allowing full bump and droop travel without bind. Rear triple-rate coils provide softer droop and ride rates with a firmer overload rate for on-road comfort, bottoming resistance, and off-road performance. ICON 2.0 Aluminum Series internal reservoir rear shocks provide vehicle-specific valving.
