MORIMOTO 4BANGER DITCH LIGHT KIT: 2

The Morimoto 4Banger A-Pillar LED system is designed to provide additional lighting, aimed precisely. It offers versatility, from long-range spotlights for high-speed driving to ditch lights for illuminating the side of the road. This A-Pillar kit includes high-performance 4Banger LED pods with a choice of beam pattern, installation brackets, and a switched wire harness.

Engineered specifically for the 2019+ Sierra 1500, the kit ensures perfect compatibility with pre-existing mounting points, making installation modification-free. The brackets are laser-cut from 304 stainless steel, electroplated, and powder-coated for durability.

The yellow-output version is designed for optimal performance in rain, snow, or fog, utilizing Phosphor-Converted Yellow LEDs for effective penetration through atmospheric particles without compromising output. The product features a copper DTP (direct thermal path) PCB for maximum heat transfer, and a cast aluminum shell that is electroplated and powder-coated to resist flaking. Potted internals, over-molded input wiring, and a main gasket are designed to IP69K standards for full weather resistance.

The patent-pending 4Banger LED pod light uses LucidShape to optimize performance with Nichia and Osram LEDs. It is available with Wide/Fog, Spot, and Combo beam patterns. The NCS Combo Beam provides a blend of width and distance, illuminating a clear path with medium range, featuring an 8H x 4V oval hot spot with a 10V degree spread at beam center.

The optional wire harness includes a triple-sealed proprietary 4-pin relay, over-molded inline fuse holder with 20A mini fuse, DT06-2S female outputs with dual seals, stainless steel power and ground terminals, and a proprietary M-Spec push-button switch with an amber-LED backlight. The A-Pillar brackets are compatible with LED pods from most other brands. When aimed properly, the Spot and Combo beams comply with SAE J581 standards for auxiliary high beams. The NCS and HXB Wide Beam models comply with SAE F regulation for street-legal fog lights when aimed at -4 degrees.
