MS3 Magic Stick 3 Camshaft 238/242 .600 112 LSA

The Texas Speed MS3 Magic Stick 3 Camshaft is a popular choice for enthusiasts seeking maximum power from stock displacement engines, particularly when utilizing nitrous oxide. Engineered for max effort, this camshaft boasts specifications of 238/242 duration and .600"/.600" lift, with a 112 LSA and 110 ICL. This camshaft is optimized for 5.7L and 6.0L LS-based engines and is designed to achieve a desired compression ratio of 10.5:1. It is compatible with stock, untouched heads without piston-to-valve clearance issues, though measuring is always recommended. The estimated power increase is between 60-65+ horsepower. Significant supporting modifications are required for optimal performance. For automatic transmissions, an aftermarket stall converter with a rating of 3800+ RPM is necessary. Additionally, upgraded rear gears of 3.42 or higher are recommended for maximum performance. Drivability can be challenging for daily driving, but adequate tuning can make it feasible, positioning it more as a weekend warrior street/strip camshaft with an operating RPM range of 2500-7000. Important installation notes include the requirement for a DOD/AFM delete for equipped engines and a VVT delete kit for VVT engines. If installing on an engine originally equipped with a 1-bolt camshaft, a 3-bolt conversion kit will be necessary. Tuning is mandatory for both automatic and manual applications.
