JE Pistons Ring Sets 1.2-1.2-2.0-86.50 PVD RS

Piston Ring Set, 4 Cyl., File Fit, 0.0472 in. Carbon Steel PVD Top Ring, 0.0472 in. Carbon Steel Phosphate Second Ring, 0.0787 in. Carbon Steel Nitride Low Tension Oil Ring, Each. JE Piston Rings are designed to maximize horsepower through precision sealing of combustion pressure. They are offered in a huge selection of sizes, various materials, and in multiple thicknesses to suit a wide variety of engines. JE Pistons also offers an array of custom piston ring services including back cutting, dyke cutting, lapping, grinding, and PVD coating. These services, the same used by top NHRA Pro Stock and NASCAR teams, are now available to the public and offer tremendous gains in durability, power through reduced friction, and improved ring seal. - Highest quality ductile iron top ring with plasma-moly inlay - Taper faced reverse torsional second rings - combined with standard or low tension oil rings. Bore Diameter: 3.405 Ring Type: 3 Ring File Fit: Yes Top Ring Axial Height: 1.20 Top Ring Radial Width: 0.120 Top Compression Ring Thickness: 0.0472 Top Ring Facing Material: PVD Top Ring Material: Carbon Steel Top Ring Shape: Barrel Face, Back Cut Second Ring Axial Height: 1.20 Second Ring Radial Width: 0.118 Second Compression Ring Thickness: 0.0472 Second Ring Facing Material: Phosphate Second Ring Material: Carbon Steel Second Ring Shape: Napier, Back Cut, Neutral Oil Ring Axial Height: 2.00 Oil Ring Radial Width: 0.126 Oil Ring Thickness: 0.079 Third Ring Facing Material: Carbon Steel Third Ring Material: Carbon Steel Third Ring Shape: Flex Vent Ring Set Thickness: 0.0472 in. Top x 0.0472 in. 2nd x 0.079 in. Oil Product Type: Engine Piston Ring Set Industry: Automotive Category Hierarchy: Auto>Accessories>Rings Out of Stock Message: Call for Availability Title - Web: Piston Ring Set - 3.405 in. Bore - 0.0472 in. Top / 0.0472 in. 2nd / 0.079 in. Oil - 4 Cyl. Engine Type: ICE Bore Diameter - Web: 3.405 IN / 86.49 MM EBAY Category ID: 33623
