PLUG AND PLAY SWITCH ILLUMINATION H

The Cali Raised CR2427 is a plug-and-play switch illumination harness designed to light up aftermarket switches. It connects to a factory connector to borrow the illumination circuit, eliminating the need for splicing. This harness allows aftermarket switches to light up with the rest of your truck's interior lights and be dimmable via the dash dimmer.

Each harness includes an extra green connector that replaces the one included with CH4x4/Cali-Raised/AOB/MIC-Tuning Toyota-style switches. The base harness illuminates one switch, and a daisy chain harness can be added to illuminate an additional switch. The system can safely illuminate up to seven switches with a base harness and six daisy chains. Installation involves plugging the harness into the cargo light connector (for 3rd Gen Tacomas) and attaching the green connector to your switch, with remaining wires connected per the switch manufacturer's diagram.
