pricing only use components 4 SYSTEM W ALUM UCA and 3.0 C O and 3.0 RR SMOOTH 17-20 RAPTOR

Fabtech 4" System W/ Alum Uca & 3.0 C/O & 3.0 Rr Smooth 17-20 Ford Raptor (2017-2020 F-150) - K2366DL 4" SYSTEM W/ ALUM UCA & 3.0 C/O & 3.0 RR SMOOTH 17-20 FORD RAPTOR In-field testing and multiple vehicle fit checks ensure products will fit properly during installation and provide years of trouble free service with superior vehicle ride qualities. When you're ready to run 37in. tires on your Raptor and have the ultimate shock system to go with it then this is the kit for you. The lift features heavy duty ductile iron steering knuckles designed to handle 37in. tall tires with the vehicle’s ESC (electronic stability control) and Traction Control. Typically, 37in. tires will cause steering and brake issues on the factory Ford steering knuckles. Fabtech knuckles are designed for the oversized tires and will provide years of trouble free service. The lower Raptor control arms are relocated with 1/4in. thick steel Crossmembers and comes with a 1/4in. thick steel differential skid plate. To keep the front CV angles proper with the new ride height, the front differential is relocated down between the crossmembers for smooth 4WD operation. Fabtech’s Billet Aluminum Upper Control Arms replace the factory weak ball joint arms for severe offroad use with superior construction and awesome looks. The Billet UCA feature 1.25 Stainless Uniballs and 3/4in. heims at the frame for rock solid suspension performance. The front Raptor shocks are replaced with Dirt Logic 3.0 Coilovers that feature a remote reservoir compression adjuster. This allows for a compliant highway ride with the ability to adjust the compression damping for aggressive offroad use. The rear Dirt Logic 3.0 Smooth Body shocks allow for 12in. of wheel travel with a remote reservoir that has a compression adjuster for increased damping control. The Dirt Logic 3.0 shocks will provide a noticeable increase in damping for Raptor owners looking to take their vehicle to the next level in suspension performance. These race quality Coilovers directly replace the stock Raptor Coilovers with improved offroad damping for aggressive driving in the most punishing conditions. They provide an additional 10% of wheel travel for a total of 11in. when used with uniball upper control arms. The Dirt Logic 3.0 shocks are constructed with a steel body and finishe Located in Chino, California our headquarters spans across five acres. The custom building was constructed to Fabtech's specification for in house development, manufacturing, distribution and administration. The 100,000 square foot facility is divided into designated departments that can operate as a single unit or collectively as a group. This allows Fabtech to function 24 hours a day as needed without compromising security, capacity or quality of the operations. Fabtech's development capabilities are second to none with over 25 years of experience in aftermarket suspension design. State of the art software, fabrication equipment along with our seasoned engineers and fabricators allow the company to develop products that are constantly on the cutting edge. Fabtech has received numerous awards for their designs that continue to lead the market. Proper design in suspension development is key in providing a quality, trouble free product to the end consumer. Fabtech leads the industry with extensive research, design technology and rigorous testing that results in the highest performing, finest quality suspension system for the discerning offroad enthusiast. New vehicle platforms now require a full integration of the vehicles electronics and sensors into the suspension design in order for the vehicle to properly function. Fabtech has invested into proprietary development processes and technologies to aid in properly designing new vehicle suspension systems that lead the industry. To ensure product quality, Fabtech builds all of its componentry in house. The manufacturing division is a world class lean environment dedicated to consistently producing quality parts in low or high volume production runs. Multiple laser cutters, robotic welders, forming equipment, machining centers and skilled welders provide flexibility and quality to its production. Packaging, warehousing and distribution are contained within the building for immediate shipment worldwide.
