T28 Turbo Kit

The Rev9 TCK-086_1 is a Stage 1 turbo kit setup engineered for Scion FR-S and Toyota 86 models equipped with the FA20 engine, covering model years 2013-2021. This comprehensive kit aims to significantly enhance performance by introducing forced induction. The core components include a cast turbocharger equal runner manifold designed to fit the FA20 motor, a T28 turbocharger rated for 300-350 HP with a .60 A/R compressor and a T25 flange type, and a 38mm wastegate pre-set at 5 PSI, with an included extra 10 PSI spring to achieve a maximum setting of 15 PSI. The kit also features an oil line kit with all necessary fittings for oil feed and return, and a front mount intercooler. Turbocharger specifications detail a 3" inlet, 2" outlet, .60 A/R compressor trim, and compressor wheel dimensions of 71mm / 52mm. The turbine wheel measures 46mm / 53mm with a .64 A/R exhaust trim. The intercooler boasts a bar and plate design with 2.5" inlet/outlet, a core size of 20" x 11" x 3", and an overall size of 25" x 15". This setup kit requires proper ECU tuning for optimal operation and performance.
