VS2225 .625 LS Beehive Valve Springs

The Texas Speed VS2225 .625 LS Beehive Valve Springs are meticulously engineered for maximum performance and durability within high-performance LS engines. The .625" max lift and 340 lbs/inch spring rate ensure excellent performance without the added weight and stress typically associated with conventional valve springs, making them an ideal choice for both street performance and track applications. The beehive design is a key feature, enhancing valve train stability, particularly at high RPMs. This design also contributes to lighter weight at the top of the spring, which reduces valve float and allows for higher rev limits. The springs offer excellent compatibility with LS engine platforms and are well-suited for use with high-lift camshafts. Key specifications include a .625" max lift, 340 lbs/inch spring rate, 1.800" installed height, 135 lbs closed pressure, and 348 lbs open pressure. The coil bind height is 1.100", with various inner and outer diameter measurements for the small and large ends. It is important to note that these springs are specifically tuned for LS engines, which limits their compatibility with other engine platforms.
