XSONIC AIRMAR B175H-W (20 )

Get more coverage under your boat with Airmar’s unique wide-beam, high-frequency, Chirp-ready B175HW. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high-frequency band delivers superior performance, bottom detail, and fish-target separation. The constantly wide beam provides twice the coverage for detecting fish in the upper-water column and clear fish arches on the display compared to most high-frequency, narrow-beam transducers. The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 152 m (500'). Tilted Element™ transducers have the element fixed at either a 20°, 12°, or 0° angle within the housing. Because the transducer is installed almost flush to the hull, the tilt corrects for the hull deadrise. It orients the ceramic element horizontally to ensure maximum echo returns to the transducer. The B175HW is available in three Tilted Element models: Fixed 20° tilted version for 16 to 24° hull deadrise angles, Fixed 12° tilted version for 8 to 15° hull deadrise angles, Fixed 0° tilted version for 0 to 7° hull deadrise angles. This transducer is available in two options: one with an OEM connector designed specifically for your fishfinder, and another as a Mix and Match™ Transducer version, which has a 9-meter (29.5’) cable with a standard connector, plus a 1-meter (3’) adapter cable to connect it to your fishfinder. When placing your order, make sure you know which connector type your fishfinder requires.
